Features and specifications.
- A bed-warming system combined with a yellowing lamp to help care for infants, premature infants or children with chronic illnesses in the operating room, delivery room or in kindergarten is easier.
- Microprocessor controlled, precise temperature control for children.
- Automatic control mode and semi-automatic mode.
- There is a switch to turn on the heating, yellow light treatment, separate examination lamp.
- The mattress can be tilted to allow the patient to be placed in bed and managed better.
Large bed mattress, which helps to accommodate older babies, and easily identifies problems with the naked eye through warnings.
- There are screens on the four sides of the mattress. The panels are made of transparent plastic, easy to observe patients from a distance. The front and side panels can be lowered for easier access.
- The mattress is made of non-X-ray material. X-rays can be taken in bed.
- For every minute, the timer will output the signal with sound and light. So the user can easily check the warming up time.
- When an error occurs, the machine displays an error message on the screen. The user can easily detect and solve the problem via the on-screen message.
- Bed with 1 Halogen bulb illuminated by cold light. Helps bring comfort to patients as well as doctors, nurses.
- The two sides of the lamp have two built-in yellow light bulbs. It can be warm, just visit and treat jaundice for patients.
- The lamp can be turned horizontally 900 to facilitate the doctors, nurses to perform special surgery, surgery or x-ray.
- The body of the bed is covered with a layer of disinfection paint. The foldable body of the bed makes it easy to move.
- There is an x-ray cassette tray. The tray is located to the right of the bed and under the mattress. Tray can be pulled out, easily inserted. Dimensions: 10 x 12 inches.
- There is a storage compartment below the mattress. The chamber is 490 x 490 mm wide and is divided into two compartments, with doors open on both sides
- The legs are designed to be wide and firm, the corners are curved, safe for the user. The outside is covered with a disinfectant paint. Easy to clean and disinfect.
- Safety alarm function.
Alarms for power failure, system error, over temperature, skin temperature, sensor and air temperature.
When the above warning conditions occur, the corresponding indicator light will blink and the alarm will sound.
+ If the skin temperature rises above 10 ° C or higher, the power supply for the burn resistance will automatically shut down to prevent further rise in temperature.
- Temperature range: 35 - 380. Resolution: 0.10C.
- Temperature range: 20 - 370. Resolution: 0.10C.
- Timer display range: 1 - 99 minutes. Every passing minute, the sound will emit. There is an audio interrupt button.
- Remote controll:
The controller is located on the front of the heated bed.
+ The controller has 10 keys.
+ 05 LED display for parameters such as skin temperature, air temperature, set temperature, timer, humidity.
+ Auto mode and semi-automatic mode display.
+ Show alarm events on the controller.
- Fire resistance:
+ Bed with 2 fire resistant.
+ Fire resistance is made of pottery, longevity.
The heat-flux principle of thermal resistance is thermal radiation along the surface of the bed. Warm but not warm up the user.
- yellow light;
+ There are 02 yellow light treatment bulbs.
+ The capacity of each light bulb is 20 W
+ Long life of 2000 hours of use.
- Halogen bulbs:
+ One halogen bulb.
+ The light output is 20W.
Illumination intensity: 3000 Lux.
+ Lamp life: 2000 hours.
- Mattress:
+ Can be tilt control, angle control is from 0 to 100.
Dimension: 680 x 560 x 30 mm. (Long x Width x Thick)
+ The mattress is covered with a layer of material to help prevent water and liquids.
+ Removable mattress, cleaning and easy cleaning.
- There are four wheels. Wheel diameter 4 inch. Wheels have brake brakes.
- Size of the bed: 500 x 700 x 1770 mm. (Width x Depth x Height)
- Maximum power consumption
+ Of burn resistance: 650 W.
Controller's: 45 W.
+ Halogen bulb: 20 W.
+ The treatment of yellow light bulbs: 40 W
- Full bed weight: 100 kg.
- Power supply: 220 V; 50 Hz.
