Specifications
Type of sample: whole blood, serum, plasma, dialysate
It is possible to set the machine to operate in save mode.
Measured parameters: - pH: 6.0 - 8.0
- pCO2: 10.0-200.0Torr
- pO2: 10.0-760Torr
- cHb: 2.0 - 23.0 g / dL
- Na +: 80.0 - 200.0 mmol / L
- K +: 1.0 - 20.0 mmol / L
- Cl-: 50.0 - 200.0 mmol / L
- Ca ++: 0.5 - 5.0 mmol / L
Calculate the following parameters: cHCO₃⁻act, cHCO₃⁻std, cBE (ecf), cBE (B), cBB, ctCO₂ (P), ctCO₂ (B), sO₂ (est), BO₂, p50, p50 pO₂ (a / T), pO₂ (A / T), pO₂ (a / A, T) CtO₂ (v), ctO₂ (av), ctO₂ ([av] / a), Hct, AG, AG (K), cCa² )
Input parameters, minimum of the following information: patient ID, patient temperature, Hb, FiO₂, sex, date of birth, height, weight
Sample size: 80μl sample in capillary mode, 120μl sample in syringe mode
Analysis time (from the touch of a button to the on-screen result): 50 seconds
Sample time: 4 seconds
Display: 12 inch color touchscreen LCD
Calibration: automatic, programmable 1 and 2 points
Data storage capacity: 10,000 samples
